HC 50F AC 110v 220v Cross Flow Fan ball bearing
AC Brushless
Fan performance options:
*Bearing: Ball
*Voltage: 110v/220v
*Waterproof: IP54/IP55/IP56/IP66/IP67/IP68
| Model No. |
Size(mm) | Voltage | Current | Speed | Max Pressure | Maximum Air Flow | Noise | ||
| A | B | C | V | A | RPM | mmAq | CFM | dB | |
| HCE50090A11BF | 98 | 108 | 162 | 110 | 0.12 | 2650 | 4.5 | 30 | 37 |
| HCE50090A22BF | 220 | 0.07 | 2500 | 4.1 | 28 | 36 | |||
| HCE50190A11BF | 198 | 208 | 267 | 110 | 0.21 | 2400 | 3.8 | 85 | 40 |
| HCE50190A22BF | 220 | 0.09 | 2500 | 4.1 | 88 | 41 | |||
| HCE50240A11BF | 250 | 260 | 320 | 110 | 0.32 | 2400 | 3.9 | 110 | 40 |
| HCE50240A22BF | 220 | 0.38 | 2450 | 4.1 | 113 | 41 | |||
| HCE50290A11BF | 298 | 308 | 370 | 110 | 0.32 | 2100 | 3 | 110 | 41 |
| HCE50290A22BF | 220 | 0.14 | 2250 | 3.4 | 117 | 42 | |||
| HCE50350A11BF | 359 | 368 | 427 | 110 | 0.33 | 2000 | 2.7 | 113 | 40 |
| HCE50350A22BF | 220 | 0.15 | 2200 | 3.3 | 124 | 41 | |||
| HCE50420A11BF | 430 | 440 | 498 | 110 | 0.28 | 2000 | 2.9 | 138 | 45 |
| HCE50420A22BF | 220 | 0.25 | 2100 | 3.2 | 145 | 46 | |||
