HC 30F DC 12v 24v 48v Cross Flow Fan ball bearing
DC Brushless
Technical Feature: Control input 0-10VDC/PWM, Tach output, Locked-Rotor protection, Reverse Polarity, Over-voltage Protection, Soft Start Protection
Fan performance options:
*Bearing: Ball/Sleeve
*Voltage: 12v/24v/28v/36v/48v
*Waterproof: IP54/IP55/IP56/IP66/IP67/IP68
*Function: Tacho meter/RD/FG/PWM+Tacho meter/PWM+RD
| Model No. |
Size(mm) | Voltage | Current | Speed | Max Pressure | Maximum Air Flow | Noise | ||
| A | B | C | V | A | RPM | mmAq | CFM | dB | |
| HCD30090A12BF | 98 | 108 | 131 | 12 | 0.15 | 3200 | 1.9 | 22 | 35 |
| HCD30090A24BF | 24 | 0.08 | |||||||
| HCD30150A12BF | 160 | 170 | 196 | 12 | 0.16 | 3100 | 1.7 | 28 | 35 |
| HCD30150A24BF | 24 | 0.09 | |||||||
| HCD30190A12BF | 200 | 210 | 238 | 12 | 0.2 | 2900 | 1.7 | 35 | 35 |
| HCD30190A24BF | 24 | 0.11 | |||||||
| HCD30240A12BF | 250 | 261 | 288 | 12 | 0.2 | 2700 | 1.6 | 39 | 35 |
| HCD30240A24BF | 24 | 0.12 | |||||||
| HCD30290A12BF | 300 | 308 | 336 | 12 | 0.22 | 2600 | 1.5 | 46 | 36 |
| HCD30290A24BF | 24 | 0.13 | |||||||
| HCD30350A12BF | 360 | 370 | 397 | 12 | 0.35 | 2500 | 1.4 | 53 | 38 |
| HCD30350A24BF | 24 | 0.22 | |||||||
