9733 97x94x33mm dc blower fan dc 5v 12v 24v dc blower fan ball bearing blower fan
DC Brushless blower
Technical Feature: Control input 0-10VDC/PWM, Tach output, Locked-Rotor protection, Reverse Polarity, Over-voltage Protection, Soft Start Protection
Fan performance options:
*Bearing: Ball/Hydraulic/Sleeve
*Voltage: 3v/5v/12v/24v/28v/36v/48v
*Waterproof: IP54/IP55/IP56/IP66/IP67/IP68
*Function: Tacho meter/RD/FG/PWM+Tacho meter/PWM+RD
| Model No. |
Rated Voltage |
Operating Voltage |
Rated Current |
Speed | Max. Air Flow |
Max. Static Pressure |
Noise | ||
| VDC | VDC | A | RPM | m³/min | CFM | mmH2O | inH2O | dB | |
| HB9733L12 | 12 | 7.0～13.8 | 0.23 | 2200 | 0.43 | 15.2 | 6.6 | 0.26 | 36 |
| HB9733M12 | 12 | 7.0～13.8 | 0.5 | 3000 | 0.57 | 20.1 | 13.2 | 0.52 | 45 |
| HB9733H12 | 12 | 7.0～13.8 | 1 | 3800 | 0.74 | 26.2 | 23.4 | 0.92 | 51 |
| HB9733U12 | 12 | 7.0～13.8 | 1.2 | 4500 | 0.88 | 31.2 | 38.5 | 1.52 | 56 |
| HB9733L24 | 24 | 14.0～27.6 | 0.13 | 2200 | 0.43 | 15.2 | 6.6 | 0.26 | 36 |
| HB9733M24 | 24 | 14.0～27.6 | 0.3 | 3000 | 0.57 | 20.1 | 13.2 | 0.52 | 45 |
| HB9733H24 | 24 | 14.0～27.6 | 0.5 | 3800 | 0.74 | 26.2 | 23.4 | 0.92 | 51 |
| HB9733U24 | 24 | 14.0～27.6 | 0.6 | 4500 | 0.88 | 31.2 | 38.5 | 1.52 | 56 |
| HB9733L48 | 48 | 28.0～56.0 | 0.09 | 2200 | 0.43 | 15.2 | 6.6 | 0.26 | 36 |
| HB9733M48 | 48 | 28.0～56.0 | 0.15 | 3000 | 0.57 | 20.1 | 13.2 | 0.52 | 45 |
| HB9733H48 | 48 | 28.0～56.0 | 0.21 | 3800 | 0.74 | 26.2 | 23.4 | 0.92 | 51 |
| HB9733U48 | 48 | 28.0～56.0 | 0.3 | 4500 | 0.88 | 31.2 | 38.5 | 1.52 | 56 |
