80mm dc fan 5v 12v 24volt 48 v 8cm fans 8038 80x80x38mm
Technical Feature: Control input 0-10VDC/PWM, Tach output, Locked-Rotor protection, Reverse Polarity, Over-voltage Protection, Soft Start Protection
Fan performance options:
*Bearing: Ball/Hydraulic/Sleeve
*Voltage: 3v/5v/12v/24v/28v/36v/48v
*Waterproof: IP54/IP55/IP56/IP66/IP67/IP68
*Function: Tacho meter/RD/FG/PWM+Tacho meter/PWM+RD
80mm dc fan, Get Sample
| Model No. |
Rated Voltage |
Operating Voltage |
Rated Current |
Speed | Max. Air Flow |
Max. Static Pressure |
Noise | ||
| VDC | VDC | A | RPM | m³/min | CFM | mmH2O | inH2O | dB | |
| HD8038L12 | 12 | 7.0～13.8 | 0.5 | 4500 | 1.81 | 63.8 | 12.4 | 0.49 | 49.5 |
| HD8038M12 | 12 | 7.0～13.8 | 1 | 6000 | 2.34 | 82.6 | 21.4 | 0.84 | 58 |
| HD8038H12 | 12 | 7.0～13.8 | 2 | 7500 | 2.9 | 102.4 | 32.5 | 1.28 | 63.5 |
| HD8038U12 | 12 | 7.0～13.8 | 2.8 | 8500 | 3.39 | 119.6 | 40.8 | 1.61 | 66 |
| HD8038L24 | 24 | 14.0～27.6 | 0.3 | 4500 | 1.81 | 63.8 | 12.4 | 0.49 | 49.5 |
| HD8038M24 | 24 | 14.0～27.6 | 0.5 | 6000 | 2.34 | 82.6 | 21.4 | 0.84 | 58 |
| HD8038H24 | 24 | 14.0～27.6 | 1 | 7500 | 2.9 | 102.4 | 32.5 | 1.28 | 63.5 |
| HD8038U24 | 24 | 14.0～27.6 | 1.5 | 8500 | 3.39 | 119.6 | 40.8 | 1.61 | 66 |
| HD8038L48 | 48 | 28.0～56.0 | 0.2 | 4500 | 1.81 | 63.8 | 12.4 | 0.49 | 49.5 |
| HD8038M48 | 48 | 28.0～56.0 | 0.3 | 6000 | 2.34 | 82.6 | 21.4 | 0.84 | 58 |
| HD8038H48 | 48 | 28.0～56.0 | 0.5 | 7500 | 2.9 | 102.4 | 32.5 | 1.28 | 63.5 |
| HD8038U48 | 48 | 28.0～56.0 | 0.8 | 8500 | 3.39 | 119.6 | 40.8 | 1.61 | 66 |
