8025 80x80x25mm Ac Axial Fan

AC-8025

HA8025-1

HDH Axial Fan ac 110v 220v 380v 8025 80x80x25mm

* Impeller: Plastic (Black) 94V-0

* Material of Housing: Aluminum Alloy

* Lead Wires: UL type or Equivalent

* Operating Temperature: -25℃~+70℃，5%~90%RH

*Storage Temperature: -40℃~+80℃，5%~90%RH

* Weight:240g

Categories: AC Cooling Fan/ Axial fan

Tags: 80mm fan/ac axial fan

Description

8025 80x80x25mm Ac Axial Fan Ac 110v 220v 380v ball bearing axial fan

AC Brushless Axial fan

Fan performance options:
*Bearing: Ball/Hydraulic/Sleeve
*Voltage: 110v/220v/380v
*Waterproof: IP54/IP55/IP56/IP66/IP67/IP68

Model No.	Bearing System	Rated Voltage	Frequency	Current	Input Power	Speed	Air Flow	Static Pressure	Noise
Model No.	Bearing	VDC	Hz	A	W	RPM	CFM	mmH2O	dB
HA8025S(B)1HL	Ball	110	50/60	0.13/0.11	17/15	2600/3000	21/24	4/5.5	28.2/33
HA8025S(B)1ML	Ball	110	50/60	0.11/0.10	13/10	2300/2600	18/21	2.9/3.4	28.2/33
HA8025S(B)2HL	Ball	220	50/60	0.09/0.08	17/15	2600/3000	21/24	4/5.5	28.2/33
HA8025S(B)2ML	Ball	220	50/60	0.06/0.05	13/10	2300/2600	18/21	2.9/3.4	28.2/33
