6030 60x60x30mm Ac Axial Fan

AC-6030

6030-1

HDH Axial Fan ac 110v 220v 380v 6030 60x60x30mm

* Impeller: Plastic (Black) 94V-0

* Material of Housing: Aluminum Alloy

* Lead Wires: UL type or Equivalent

* Operating Temperature: -25℃~+70℃，5%~90%RH

*Storage Temperature: -40℃~+80℃，5%~90%RH

* Weight:145g

Categories: AC Cooling Fan/ Axial fan

Tags: 110V/220V/380V/60mm fan/ac axial fan/ac cooling fan/ac fan/axial dc cooling fan/axial fan/brushless cooling fan

Description

6030 60x60x30mm Ac Axial Fan Ac 110v 220v 380v ball bearing axial fan

AC Brushless Axial fan 60mm

Fan performance options:Metal
*Bearing: Ball/Hydraulic/Sleeve
*Voltage: 110v/220v/380v
*Waterproof: IP54/IP55/IP56/IP66/IP67/IP68

Model No.	Bearing System	Rated Voltage	Frequency	Current	Input Power	Speed	Air Flow	Static Pressure	Noise
Model No.	Bearing	VDC	Hz	A	W	RPM	CFM	mmH2O	dB
HA6030B1HL	Ball	110	50/60	0.042/0.035	5/4	2500/3000	7.9/10	1.6/2.7	26/27
HA6030B2HL	Ball	220	50/60	0.022/0.02	5/4	2500/3000	7.9/10	1.6/2.7	26/28
