6018 61x62x18mm dc blower fan dc 5v 12v 24v dc blower fan ball bearing blower fan
DC Brushless blower
Technical Feature: Control input 0-10VDC/PWM, Tach output, Locked-Rotor protection, Reverse Polarity, Over-voltage Protection, Soft Start Protection
Fan performance options:
*Bearing: Ball/Hydraulic/Sleeve
*Voltage: 3v/5v/12v/24v/28v/36v/48v
*Waterproof: IP54/IP55/IP56/IP66/IP67/IP68
*Function: Tacho meter/RD/FG/PWM+Tacho meter/PWM+RD
| Model No. |
Rated Voltage |
Operating Voltage |
Rated Current |
Speed | Max. Air Flow |
Max. Static Pressure |
Noise | ||
| VDC | VDC | A | RPM | m³/min | CFM | mmH2O | inH2O | dB | |
| HB6018L12 | 12 | 7.0～13.8 | 0.15 | 3500 | 0.12 | 4.19 | 6.35 | 0.25 | 36.1 |
| HB6018M12 | 12 | 7.0～13.8 | 0.2 | 4500 | 0.16 | 5.6 | 12.19 | 0.48 | 43.6 |
| HB6018H12 | 12 | 7.0～13.8 | 0.3 | 5500 | 0.19 | 6.73 | 20 | 0.79 | 48 |
| HB6018L24 | 24 | 14.0～27.6 | 0.08 | 3500 | 0.12 | 4.19 | 6.35 | 0.25 | 36.1 |
| HB6018M24 | 24 | 14.0～27.6 | 0.12 | 4500 | 0.16 | 5.6 | 12.19 | 0.48 | 43.6 |
| HB6018H24 | 24 | 14.0～27.6 | 0.2 | 5500 | 0.19 | 6.73 | 20 | 0.79 | 48 |
