3010 30x30x10mm dc blower fan dc 5v 12v 24v dc blower fan ball bearing blower fan
DC Brushless blower
Technical Feature: Control input 0-10VDC/PWM, Tach output, Locked-Rotor protection, Reverse Polarity, Over-voltage Protection, Soft Start Protection
Fan performance options:
*Bearing: Ball/Hydraulic/Sleeve
*Voltage: 3v/5v/12v/24v/28v/36v/48v
*Waterproof: IP54/IP55/IP56/IP66/IP67/IP68
*Function: Tacho meter/RD/FG/PWM+Tacho meter/PWM+RD
| Model No. |
Rated Voltage |
Operating Voltage |
Rated Current |
Speed | Max. Air Flow |
Max. Static Pressure |
Noise | ||
| VDC | VDC | A | RPM | m³/min | CFM | mmH2O | inH2O | dB | |
| HB3010L05 | 5 | 4.0～5.75 | 0.15 | 7000 | 0.028 | 1 | 2.03 | 0.08 | 24 |
| HB3010M05 | 5 | 4.0～5.75 | 0.21 | 9000 | 0.034 | 1.2 | 4.06 | 0.16 | 28 |
| HB3010H05 | 5 | 4.0～5.75 | 0.35 | 12000 | 0.044 | 1.57 | 7.62 | 0.3 | 35 |
| HB3010L12 | 12 | 7.0～13.8 | 0.09 | 7000 | 0.028 | 1 | 2.03 | 0.08 | 24 |
| HB3010M12 | 12 | 7.0～13.8 | 0.13 | 9000 | 0.034 | 1.2 | 4.06 | 0.16 | 28 |
| HB3010H12 | 12 | 7.0～13.8 | 0.18 | 12000 | 0.044 | 1.57 | 7.62 | 0.3 | 35 |
