14051 140x140x51mm dc fan dc 5v 12v 24v dc axial fan ball bearing cooling fan
DC Brushless mini fan
Technical Feature: Control input 0-10VDC/PWM, Tach output, Locked-Rotor protection, Reverse Polarity, Over-voltage Protection, Soft Start Protection
Fan performance options:
*Bearing: Ball/Hydraulic/Sleeve
*Voltage: 3v/5v/12v/24v/28v/36v/48v
*Waterproof: IP54/IP55/IP56/IP66/IP67/IP68
*Function: Tacho meter/RD/FG/PWM+Tacho meter/PWM+RD
| Model No. |
Rated Voltage |
Operating Voltage |
Rated Current |
Speed | Max. Air Flow |
Max. Static Pressure |
Noise | ||
| VDC | VDC | A | RPM | m³/min | CFM | mmH2O | inH2O | dB | |
| HD1451L24 | 24 | 14.0～27.6 | 0.8 | 2800 | 6.2 | 218.88 | 12.7 | 0.5 | 56.4 |
| HD1451M24 | 24 | 14.0～27.6 | 1.2 | 3200 | 7.09 | 250.15 | 16.7 | 0.66 | 59.7 |
| HD1451H24 | 24 | 14.0～27.6 | 2 | 3600 | 7.97 | 281.42 | 21 | 0.83 | 62.6 |
| HD1451L48 | 48 | 28.0～56.0 | 0.5 | 2800 | 6.2 | 218.88 | 12.7 | 0.5 | 56.4 |
| HD1451M48 | 48 | 28.0～56.0 | 0.7 | 3200 | 7.09 | 250.15 | 16.7 | 0.66 | 59.7 |
| HD1451H48 | 48 | 28.0～56.0 | 1 | 3600 | 7.97 | 281.42 | 21 | 0.83 | 62.6 |
