12025 cooling fan 12025 120x120x25mm 5v 12v 24v dc axial fan
DC 12cm 12038 Silent 5V12V 24V 48V Chassis Inverter USB 5v Fan
High temperature resistance, corrosion resistance, salt spray resistance, dust resistance, moisture resistance, waterproof IP55/IP68 glue filling
Technical Feature: Control input 0-10VDC/PWM, Tach output, Locked-Rotor protection, Reverse Polarity, Over-voltage Protection, Soft Start Protection
Fan performance options:
*Bearing: Ball/Hydraulic/Sleeve
*Voltage: 3v/5v/12v/24v/28v/36v/48v
*Waterproof: IP54/IP55/IP56/IP66/IP67/IP68
*Function: Tacho meter/RD/FG/PWM+Tacho meter/PWM+RD
Please contact us for samples:12025 cooling fan
| Model No. |
Rated Voltage |
Operating Voltage |
Rated Current |
Speed | Max. Air Flow |
Max. Static Pressure |
Noise | ||
| VDC | VDC | A | RPM | m³/min | CFM | mmH2O | inH2O | dB | |
| HD1225L05 | 5 | 4.0～5.75 | 0.4 | 1500 | 1.61 | 56.9 | 1.9 | 0.07 | 29 |
| HD1225M05 | 5 | 4.0～5.75 | 0.6 | 1800 | 1.93 | 68.3 | 2.8 | 0.11 | 34 |
| HD1225L12 | 12 | 7.0～13.8 | 0.23 | 1500 | 1.61 | 56.9 | 1.9 | 0.07 | 29 |
| HD1225M12 | 12 | 7.0～13.8 | 0.3 | 1800 | 1.93 | 68.3 | 2.8 | 0.11 | 34 |
| HD1225H12 | 12 | 7.0～13.8 | 0.4 | 2100 | 2.26 | 79.7 | 3.8 | 0.15 | 38 |
| HD1225L24 | 24 | 14.0～27.6 | 0.13 | 1500 | 1.61 | 56.9 | 1.9 | 0.07 | 29 |
| HD1225M24 | 24 | 14.0～27.6 | 0.18 | 1800 | 1.93 | 68.3 | 2.8 | 0.11 | 34 |
| HD1225H24 | 24 | 14.0～27.6 | 0.23 | 2100 | 2.26 | 79.7 | 3.8 | 0.15 | 38 |
