1125 110x110x25mm Ac Axial Fan

AC-1125

HA11025-1

HDH Axial Fan ac 110v 220v 380v 1125 110x110x25mm

* Impeller: Plastic (Black) 94V-0

* Material of Housing: Aluminum Alloy

* Lead Wires: UL type or Equivalent

* Operating Temperature: -25℃~+70℃，5%~90%RH

*Storage Temperature: -40℃~+80℃，5%~90%RH

* Weight:300g

Categories: AC Cooling Fan/ Axial fan

Tags: ac axial fan/ac cooling fan/axial dc cooling fan/axial fan/brushless cooling fan/cooling fan

Description

1125 110x110x25mm Ac Axial Fan Ac 110v 220v 380v ball bearing axial fan

AC Brushless Axial fan

Fan performance options:
*Bearing: Ball/Hydraulic/Sleeve
*Voltage: 110v/220v/380v
*Waterproof: IP54/IP55/IP56/IP66/IP67/IP68

Model No.	Bearing System	Rated Voltage	Frequency	Current	Input Power	Speed	Air Flow	Static Pressure	Noise
Model No.	Bearing	VDC	Hz	A	W	RPM	CFM	mmH2O	dB
HA1125S(B)1HL	SleeveBall	110	50/60	0.15/0.14	17/15	2300/2700	39/45	3.9/4.1	35/37
HA1125S(B)1ML	SleeveBall	110	50/60	0.11/0.10	12/10	1800/2400	30/37	2.2/2.50	30/35
HA1125S(B)2HL	SleeveBall	220	50/60	0.11/0.09	17/15	2300/2700	39/45	3.9/4.1	35/37
HA1125S(B)2ML	SleeveBall	220	50/60	0.19/0.07	12/10	1800/2400	30/37	2.2/2.50	30/35
